MapSphere converts survey, GIS, raster, and field data into clean, structured CAD drawings for engineering, planning, construction, and documentation — built to your drafting standards.

We deliver MicroStation- and AutoCAD-style outputs for planimetric, topographic, utility, and corridor drawings, fully layered and standardized.

Key deliverables

DWGDXFDGNPlan drawingsUtility drawingsCAD layers
What we do

Scope of work

  • CAD drafting
  • Raster to CAD
  • Survey drawing preparation
  • Planimetric & topographic CAD
  • Utility CAD
  • Road / corridor CAD
  • 2D plan / construction plan
Deliverables

What you receive

  • DWG
  • DXF
  • DGN
  • Plan drawings
  • Utility drawings
  • CAD layers
Gallery

Sample outputs

CAD Services output 1
CAD Services output 2
CAD Services output 3
Applications

Where it’s used

Civil engineering
Infrastructure
Land development
Roads & rail
Utility documentation
Workflow

How we deliver it

01

Project Scope

Understand site, objective, deliverables, timeline, and accuracy needs.

02

Survey Planning

Select the right method — UAV, DGPS, Total Station, LiDAR, GPR, Bathymetry, or hybrid.

03

Data Capture

Collect field, aerial, scan, image, and control data with approved instruments and trained teams.

04

Processing & Modeling

Convert raw data into GIS, CAD, BIM, orthophotos, point clouds, DTM/DSM/DEM, and maps.

05

Quality Validation

Validate accuracy, topology, alignment, coordinate system, completeness, and standards.

06

Final Delivery

Deliver maps, drawings, reports, spatial databases, models, and decision-ready outputs.

Related

Related services

BIM Modeling & MappingBIM Modeling

Scan-to-BIM, coordination, clash detection, and as-built models.

BIM modelsRevit modelsLOD 100 – 500
View Details
PLS CAD — Transmission Line DesignPLS CAD

PLS-CADD transmission line modeling, sag-tension, and tower spotting.

PLS-CADD modelsSag-tension reportsTower schedules
View Details
FAQ

CAD Services — common questions

01What source data can you turn into CAD?

We work from total-station and DGPS survey data, GIS layers, scanned raster drawings, LiDAR/point-cloud extractions, and drone-derived orthophotos — converting any of them into clean, layered DWG, DXF, or DGN drawings.

02Do you follow our CAD standards?

Yes. We draft to National CAD Standards (NCS) or your in-house layer, line-weight, and naming conventions. Provide a template or sample sheet and every deliverable will match it exactly.

03Can you do raster-to-CAD vectorization?

We vectorize scanned and raster drawings into fully editable, layered CAD — recovering planimetric detail, utilities, and corridor geometry as intelligent linework rather than a static image.
